Logistic Regression

Logistic Regression is the go-to algorithm for binary classification (problems with two possible outcomes). While Linear Regression predicts a continuous number, Logistic Regression predicts the probability that an input belongs to a specific category.

1. The Sigmoid Function

The core difference between linear and logistic regression is the Activation Function. To turn a real-valued number into a probability between $0$ and $1$, we use the Sigmoid (or Logistic) function.

The Formula:

$$\sigma(z) = \frac{1}{1 + e^{-z}}$$

Where:

• $z$ is the input (a linear combination of features).
• $e$ is Euler's number (approximately $2.71828$).

Key Properties:

• If $z$ is a large positive number, $\sigma(z)$ approaches $1$.
• If $z$ is a large negative number, $\sigma(z)$ approaches $0$.
• If $z = 0$, $\sigma(z) = 0.5$.

2. From Linear to Logistic

Logistic Regression starts by calculating a linear combination of inputs, just like Linear Regression:

$$z = \beta_0 + \beta_1x_1 + \beta_2x_2 + ...$$

It then passes that result through the Sigmoid function to get the probability ($p$):

$$p = \sigma(z)$$

3. The Decision Boundary

To make a final classification, we apply a threshold (usually $0.5$).

• If $p \geq 0.5$, classify as Class 1 (e.g., "Spam").
• If $p < 0.5$, classify as Class 0 (e.g., "Not Spam").

The line (or plane) where the probability is exactly $0.5$ is called the Decision Boundary.

4. Implementation with Scikit-Learn

from sklearn.linear_model import LogisticRegression
from sklearn.model_selection import train_test_split

# 1. Initialize the model
# 'liblinear' is a good solver for small datasets
model = LogisticRegression(solver='liblinear')

# 2. Train
model.fit(X_train, y_train)

# 3. Predict Class Labels
y_pred = model.predict(X_test)

# 4. Predict Probabilities
y_probs = model.predict_proba(X_test)[:, 1] # Probability of being Class 1

5. Cost Function: Log Loss

In Linear Regression, we use Mean Squared Error. However, because of the Sigmoid function, MSE would result in a non-convex function that is hard to optimize. Instead, Logistic Regression uses Log Loss (Cross-Entropy).

Log Loss penalizes the model heavily when it is confident about a wrong prediction.

$$J(\theta) = -\frac{1}{m} \sum_{i=1}^{m} [y^{(i)} \log(\hat{y}^{(i)}) + (1 - y^{(i)}) \log(1 - \hat{y}^{(i)})]$$

6. Multi-class Classification (One-vs-Rest)

By default, Logistic Regression is binary. To handle multiple classes (e.g., classifying an image as "Cat", "Dog", or "Bird"), Scikit-Learn uses the One-vs-Rest (OvR) strategy, where it trains one binary classifier per class.

7. Pros and Cons

Advantages	Disadvantages
Highly interpretable (you can see feature weights).	Assumes a linear relationship between features and log-odds.
Fast to train and predict.	Easily outperformed by more complex models (like Random Forests).
Provides probabilities, not just hard labels.	Can struggle with highly non-linear data.

References for More Details

• Scikit-Learn Logistic Regression Documentation: Understanding regularization parameters like C (inverse of regularization strength).
• In this video, StatQuest provides an excellent visual explanation of Logistic Regression concepts:

---

Logistic Regression is a "linear" classifier. What if your data is organized like a flowchart?
