Huffman Coding Solution

Problem Statement​

Problem Description​

Huffman Coding assigns variable-length codes to input characters, with shorter codes assigned to more frequent characters, resulting in efficient compression. Given a set of characters and their frequencies, the goal is to build a Huffman Tree and determine the Huffman codes for each character.

Examples​

Example 1:

Input: Characters = {a, b, c, d, e, f}, Frequencies = {5, 9, 12, 13, 16, 45}
Output:
a: 1100
b: 1101
c: 100
d: 101
e: 111
f: 0

Constraints​

The input should be a set of characters and their respective frequencies.

Solution of Given Problem​

Intuition and Approach​

The Huffman Coding algorithm follows these steps:

  1. Create a leaf node for each character and build a min heap of all leaf nodes.
  2. Extract two nodes with the smallest frequency from the min heap.
  3. Create a new internal node with a frequency equal to the sum of the two nodes' frequencies.
  4. Add the new node to the min heap.
  5. Repeat steps 2-4 until the heap contains only one node, which becomes the root of the Huffman Tree.
  6. Assign binary codes to each character based on their position in the Huffman Tree.

Approaches​

Codes in Different Languages​

Written by sjain1909
 #include <bits/stdc++.h>
 using namespace std;
 struct MinHeapNode {
     char data;
     int freq;
     MinHeapNode *left, *right;

     MinHeapNode(char data, int freq) {
         left = right = nullptr;
         this->data = data;
         this->freq = freq;
     }
 };

 struct compare {
     bool operator()(MinHeapNode* left, MinHeapNode* right) {
         return (left->freq > right->freq);
     }
 };
 void printCodes(struct MinHeapNode* root, string str) {
     if (!root)
         return;

     if (root->data != '$')
         cout << root->data << ": " << str << "\n";

     printCodes(root->left, str + "0");
     printCodes(root->right, str + "1");
 }

 void HuffmanCodes(char data[], int freq[], int size) {
     struct MinHeapNode *left, *right, *top;
     priority_queue<MinHeapNode*, vector<MinHeapNode*>, compare> minHeap;

     for (int i = 0; i < size; ++i)
         minHeap.push(new MinHeapNode(data[i], freq[i]));

     while (minHeap.size() != 1) {
         left = minHeap.top();
         minHeap.pop();

         right = minHeap.top();
         minHeap.pop();

         top = new MinHeapNode('$', left->freq + right->freq);

         top->left = left;
         top->right = right;

         minHeap.push(top);
     }
     printCodes(minHeap.top(), "");
 }

 int main() {
     char arr[] = {'a', 'b', 'c', 'd', 'e', 'f'};
     int freq[] = {5, 9, 12, 13, 16, 45};
     int size = sizeof(arr) / sizeof(arr[0]);

     HuffmanCodes(arr, freq, size);

     return 0;
 }

Complexity Analysis​

  • Time Complexity: O(nlog⁡n)O(n \log n)
  • Space Complexity: O(n)O(n)
  • Where n is the number of characters.
  • The time complexity is dominated by the operations on the min heap.
  • The space complexity is linear due to the storage of the Huffman Tree.
